Allen-Bradley 1734-IB8 8-Point Digital Input Module
The Allen-Bradley 1734-IB8 is a POINT I/O digital input module with 8 DC inputs, designed to interface field devices with PLC systems. It enables reliable signal acquisition from sensors and switches, supporting efficient monitoring and control in distributed industrial automation applications.
Looking for a Quote? Contact Us Now
Categories: PLC I/O Module
Description
The Allen-Bradley 1734-IB8 is a POINT I/O digital DC input module designed to collect discrete signals from field devices and transmit them to a PLC controller. It features 8 sinking input channels that operate on 24V DC, making it suitable for interfacing with sensors, switches, and other digital devices. As part of the POINT I/O system, it supports distributed I/O architectures, allowing flexible system design and reduced wiring costs.
The module is compact and DIN rail mounted, making it ideal for space-saving installations in control panels. It connects through a terminal base unit (such as 1734-TB or TBS) and offers configurable input filtering for improved signal stability. With reliable performance and easy integration into EtherNet/IP networks via adapters like 1734-AENT, it is widely used in modern industrial automation systems.
QTech Safety is a leading supplier of Allen-Bradley 1734-IB8 8-Point Digital Input Module in Ireland, offering competitive prices and fast worldwide shipping across United Kingdom (UK), Germany, France, Italy, Spain, United States USA, Canada, Mexico, and Western Australia (Perth). Buy Allen-Bradley PLC I/O module from one of Ireland’s most trusted industrial safety equipment suppliers.
Features of Allen-Bradley 1734-IB8 8-Point Digital Input Module
- 8 digital DC input channels (sinking type)
- 24V DC input voltage (10–28.8V range)
- Configurable input filter (0.5 ms to 65 ms)
- LED indicators for input and module status
- Compact DIN rail mounting design
- Requires terminal base (1734-TB or TBS)
- Low power consumption (~1.6 W)
- Supports distributed POINT I/O systems
- High noise immunity with stable signal processing
- Easy integration with EtherNet/IP adapters
- Designed for industrial environments
Technical Specifications of Allen-Bradley 1734-IB8
Product Type : | POINT I/O Digital DC Input Module |
Number of Inputs : | 8 (1 group of 8), sinking |
Voltage, On-State : | 10…28.8V DC (nominal 24V DC) |
Current, On-State : | 2 mA min, 4 mA nominal @ 24V DC, 5 mA max |
Voltage, Off-State (max) : | 5V DC |
Current, Off-State (min) : | 1.5 mA |
Input Impedance (nom) : | 3.6 kΩ |
Input Filter Time : | 0.5 ms hardware + 0…63 ms (user selectable) |
POINTBus Current (max) : | 75 mA @ 5V DC |
Power Dissipation (max) : | 1.6 W @ 28.8V DC |
Thermal Dissipation (max) : | 5.5 BTU/hr @ 28.8V DC |
Field Power Voltage Range : | 10…28.8V DC (nominal 24V DC) |
Isolation Voltage : | 50V (continuous), tested 2500V DC for 60 s |
Dimensions (H x W x D) : | 56 x 12 x 75.5 mm (2.2 x 0.47 x 2.97 in.) |
Weight (approx.) : | 32.3 g (1.14 oz) |
Operating Temperature : | -20…55 °C (-4…131 °F) |
Storage Temperature : | -40…85 °C (-40…185 °F) |
Enclosure Type : | None (open-style) |
Terminal Base : | 1734-TB or 1734-TBS |
Wire Size : | Determined by installed terminal base |
Certifications : | c-UL-us, CE, ATEX (Zone 2), KC |
Allen-Bradley 1734-IB8
Standard Part Number
- 1734-IB8
Alternate Part Number
- 1734-IB8K
