Rosemount 1195 Integral Orifice Flow Meter
Rosemount 1195 Integral Orifice Flow Meter is a compact differential pressure flowmeter designed for accurate measurement of liquids, gases, and steam in small line sizes. It features an integrated orifice and meter run design that improves accuracy, reduces installation errors, and ensures reliable flow measurement performance.
Looking for a Quote? Contact Us Now
Categories: Differential Pressure Flow Meter, Flow Meter
Description
The Rosemount 1195 Integral Orifice Flow Meter is a compact differential pressure flow measurement solution designed for accurate monitoring of liquids, gases, and steam in small line sizes. It integrates a precision orifice plate and honed meter run into a single assembly, eliminating installation errors caused by misalignment, impulse lines, and piping inconsistencies. This integrated design ensures improved accuracy, repeatability, and simplified installation compared to traditional orifice systems.
Engineered for high-performance flow measurement, the 1195 is directly mounted to Rosemount differential pressure transmitters to form a complete flow system. It is designed for clean, single-phase fluids and offers stable operation in demanding industrial environments. The self-centering orifice plate and precision-machined meter body minimize flow distortion, making it ideal for applications requiring reliable and consistent measurement in compact piping systems.
QTech Safety is a leading supplier of Rosemount 1195 Integral Orifice Flow Meter in Ireland, offering competitive prices and fast worldwide shipping across United Kingdom (UK), Germany, France, Italy, Spain, United States USA, Canada, Mexico, and Western Australia (Perth). Buy Rosemount Flow Meters from one of Ireland’s most trusted industrial safety equipment suppliers.
Features of Rosemount 1195 Integral Orifice Flow Meter
- Suitable for liquid, gas, and steam flow measurement
- High accuracy up to ±0.75% of flow rate
- Designed for small line sizes: 1/2″ to 1.5″ (15–40 mm)
- Integrated orifice and meter run for compact installation
- Self-centering orifice plate reduces installation errors
- Direct mounting to Rosemount DP transmitters
- Improves measurement repeatability and stability
- Suitable for clean, single-phase flow applications
- Reduces need for impulse lines, fittings, and tubing
- Compact design for tight piping layouts
Technical Specifications of Rosemount 1195
- Type: Integral orifice primary element for small line flow measurement
- Line sizes: ½” to 1½” (15 mm to 40 mm)
- Accuracy: Up to ±0.75% of flow rate
- Beta ratio: Multiple bore sizes available
- Process temperature: -80°C to +454°C (-112°F to +850°F)
- Max pressure: ANSI Class 900#
- Fluid types: Liquid, gas, steam
- Wetted material: 316 Stainless Steel (standard)
- Design: Self-centering orifice plate in meter run (reduces installation error)
- Mounting: Direct or remote mount with DP transmitter
Flow Meter Part Number & Configuration Guide
Standard (Example) Part Number
1195F005T1S0010C
This is a reference configuration for the Rosemount Flow Meters. It represents one commonly supplied setup and helps customers understand how the part number is structured.
Configurable Part Number Format
1195F0XXXXXXXXXX
Each X / XX in the part number indicates a selectable option that can be customized based on your application requirements such as Transmitter Feature, Line Size, Primary Element Type, Differential Pressure Range, Temperature Range, Remote Adapters & Flow Calibration.
✅ Important: Final part number depends on the exact configuration needed for your machinery, environment, and monitoring system.
Applications
The Rosemount 1195 Integral Orifice Flow Meter is commonly used in industrial calibration and testing applications, including:
- Small-line industrial process flow measurement
- Steam flow monitoring in utility systems
- Gas flow measurement in clean pipelines
- Liquid flow monitoring in chemical processes
- Energy and process control systems
