ProSoft MVI56-MCM Modbus Master/Slave Communication Module
The ProSoft MVI56-MCM is a Modbus Master/Slave Communication Module for Rockwell Automation ControlLogix® processors, giving them an easy interface to any Modbus protocol-compatible device. Built as licensed backplane technology manufactured under license from Rockwell Automation, it acts as an I/O module between the Modbus network and the ControlLogix backplane, making it compatible with Modicon PLCs and a wide range of process, control, and SCADA devices from other manufacturers.
Looking for a Quote? Contact Us Now
Categories: PLC Communication Module
Description
The ProSoft MVI56-MCM is a Modbus Master/Slave Communication Module that installs as a generic 1756 module in the ControlLogix rack, giving high-speed data transfer between the module and the processor. It supports both Modbus RTU (binary, CRC-16) and Modbus ASCII (LRC error checking) modes, and each application port can be independently configured as a virtual Master or Slave. As a Master, the module supports up to 100 commands per port, with optimized polling that reduces polling frequency for slaves reporting communication problems. As a Slave, it permits a remote Master to read and write all module data, with a configurable node address from 1 to 247.
All module configuration is defined through sample ladder logic, which is fully commented and includes user-defined data types, ladder rungs, and controller tags — usable without modification for most applications. The module also supports floating-point data movement, including Enron and Daniel-style formats, and provides diagnostics viewable directly in RSLogix™ 5000 controller tags, along with LED indicators and menu-driven hardware/protocol diagnostics for quick health checks.
QTech Safety is a leading supplier of ProSoft MVI56-MCM Modbus Master/Slave Communication Module in Ireland, offering competitive prices and fast worldwide shipping across United Kingdom (UK), Germany, France, Italy, Spain, United States USA, Canada, Mexico, and Western Australia (Perth). Buy ProSoft Communication Modules from one of Ireland’s most trusted industrial safety equipment suppliers.
Features of ProSoft MVI56-MCM Modbus Master/Slave Communication Module
- Licensed backplane technology manufactured under license from Rockwell Automation
- Installs as a Generic 1756 module with sample ladder logic included
- Each application port independently configurable as Modbus Master or Slave
- Supports both Modbus RTU and Modbus ASCII protocol versions
- Up to 100 fully configurable commands per Master port
- Optimized polling reduces frequency for problematic slave devices
- Floating-point data support, including Enron and Daniel formats
- View module data and status directly in RSLogix 5000 controller tags
- LED diagnostics and menu-driven hardware/protocol diagnostics
Technical Specifications of ProSoft MVI56-MCM
- Type: Modbus Master/Slave Communication Module
- Platform: Rockwell Automation ControlLogix® (single-slot, 1756 backplane)
- Application Ports: 2 (PRT1 & PRT2), independently configurable
- Serial Standards: RS-232, RS-422, RS-485
- Baud Rate: 110 to 115,200 baud (protocol dependent)
- Data Bits: 7 or 8; Stop Bits: 1 or 2; Parity: None, Even, Odd
- Modbus Modes: RTU (binary, CRC-16) and ASCII (LRC error checking)
- Modbus Function Codes Supported: 1, 2, 3, 4, 5, 6, 8, 15, 16, 17, 22, 23
- Master Command List: Up to 100 commands per Master port
- Slave Node Address: 1 to 247 (software selectable)
- Backplane Current Load: 800 mA @ 5 VDC, 3 mA @ 24 VDC
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C (-40°F to 185°F)
- Relative Humidity: 5% to 95% (non-condensing)
- Shock: 30g operational, 50g non-operational; Vibration: 5g (10–150 Hz)
- Configuration Port (CFG): RJ45 (DB-9M with supplied cable), RS-232 only
- Optical Isolation: 500 V from backplane on serial application ports
- LED Indicators: Module status, backplane transfer status, application status, serial activity
Applications
The ProSoft MVI56-MCM Modbus Master/Slave Communication Module is commonly used in:
- Integrating ControlLogix PLCs with Modbus RTU/ASCII serial devices
- Communicating with Modicon PLCs and other Modbus-compatible controllers
- SCADA systems requiring dual-port Master/Slave serial communication
- Flow computer and Enron/Daniel floating-point data integration
- Process control and field device interfacing on legacy ControlLogix systems
