ProSoft MVI56-BAS BASIC Communication Module (DB/BAS Compatible)
The ProSoft MVI56-BAS is a single-slot BASIC Communication Module for the ControlLogix® platform, purpose-built to migrate the large installed base of legacy BASIC programs from 1771-DB and 1747-BAS modules onto ControlLogix with minimal rework. It gives ControlLogix processors a direct interface to devices that rely on ASCII communication, such as modems, printers, bar code readers, and scales.
Looking for a Quote? Contact Us Now
Categories: PLC Communication Module
Description
The ProSoft MVI56-BAS is a BASIC Communication Module that lets users write BASIC programs to transfer data between the ControlLogix processor and third-party ASCII devices, creating a custom foreign-device interface without complex programming. Written programs run on the module’s own processor, offloading math and data-handling tasks from the ControlLogix CPU and freeing up processor memory and scan time. The module supports the BASIC-52 programming language and can run in DF1 full-duplex or half-duplex slave mode.
Programs are stored on the module’s Compact Flash disk, with up to 24,065 bytes of RAM available, and can be created via the command line or on a PC and downloaded to the module — with the option to auto-run on power-up. The module provides three communication ports: a DH-485 port for interfacing with Rockwell AIC+ devices, and two ASCII/DF1-capable ports (PRT1 and PRT2) for serial device connections. It fits into a single 1756 ControlLogix backplane slot and can be used in local or remote racks.
QTech Safety is a leading supplier of ProSoft MVI56-BAS BASIC Communication Module in Ireland, offering competitive prices and fast worldwide shipping across United Kingdom (UK), Germany, France, Italy, Spain, United States USA, Canada, Mexico, and Western Australia (Perth). Buy ProSoft Communication Modules from one of Ireland’s most trusted industrial safety equipment suppliers.
Features of ProSoft MVI56-BAS BASIC Communication Module
- Migrates legacy 1771-DB and 1747-BAS BASIC programs to ControlLogix
- Creates custom foreign-device interfaces for ASCII-based equipment
- Interfaces with modems, printers, bar code readers, and scales
- Offloads math algorithms from the ControlLogix processor to save memory
- Supports DF1 full-duplex device and half-duplex slave operation
- Stores BASIC programs on a removable Compact Flash disk for easy backup
- Configurable to auto-run a BASIC program automatically at power-up
- DH-485 port for direct interfacing with Rockwell AIC+ devices
Technical Specifications of ProSoft MVI56-BAS
- Type: BASIC Communication Module (DB/BAS Compatible)
- Platform: ControlLogix® (single-slot, 1756 backplane)
- Programming Language: BASIC-52
- Program Storage: Compact Flash disk
- Available RAM: 24,064 bytes
- Ports: DH-485 (program transfer/communication), PRT1 (ASCII communication/program port), PRT2 (ASCII or DF1 communication)
- DF1 Commands Sent: PLC-2 unprotected read/write, PLC-3 word range read/write, PLC-5 typed read/write
- DF1 Commands Accepted: PLC word range/typed writes, PLC unprotected write, SLC 5/02 unprotected/typed writes
- Baud Rate: 110 to 115,200 baud (protocol dependent)
- Serial Standards: RS-232, RS-422, RS-485
- Data Bits: 5, 6, 7, or 8; Stop Bits: 1 or 2; Parity: None, Odd, Even
- Backplane Current Load: 800 mA @ 5.1 VDC, 3 mA @ 24 VDC
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C (-40°F to 185°F)
- Relative Humidity: 5% to 95% (non-condensing)
- Shock: 30g operational, 50g non-operational; Vibration: 5g (10–150 Hz)
- Configuration Port (CFG): RJ45 (DB-9M with supplied cable), RS-232 only
- Optical Isolation: 500 V from backplane on serial application ports
Applications
The ProSoft MVI56-BAS BASIC Communication Module is commonly used in:
- Migrating legacy BASIC programs to modern ControlLogix systems
- Interfacing ControlLogix with ASCII-based modems, printers, and scanners
- Custom foreign-device integration requiring onboard math processing
- DH-485 network connectivity via Rockwell AIC+ devices
- DF1-based communication with PLC-2, PLC-3, PLC-5, and SLC 5/02 processors
