Rosemount 1066 Single Channel Transmitter
Rosemount 1066 Single Channel Transmitter is a loop-powered analytical device designed for continuous measurement of a single liquid parameter such as pH, conductivity, oxygen, or chlorine. It offers flexible communication options, intuitive operation, and reliable performance for industrial liquid analysis applications.
Looking for a Quote? Contact Us Now
Categories: pH Meters, Water Quality
Description
The Rosemount 1066 Single Channel Transmitter is engineered to support one analytical sensor input, enabling precise monitoring of parameters including pH/ORP, conductivity, resistivity, dissolved oxygen, chlorine, ozone, and temperature. It operates on a two-wire loop-powered system (minimum ~12.7 VDC), simplifying wiring and reducing installation costs while maintaining reliable signal transmission. The transmitter features a high-contrast LCD that displays primary measurements along with additional variables and diagnostics, allowing operators to monitor process conditions in real time. With support for HART® and FOUNDATION™ fieldbus communication, it integrates easily into distributed control systems (DCS) and PLC-based automation environments.
In addition, the transmitter includes Quick Start programming and intuitive menu navigation, significantly reducing commissioning time and simplifying calibration procedures. Its SMART diagnostics continuously monitor both the sensor and device health, providing alerts for faults, calibration issues, or process abnormalities to minimize downtime. Built with a rugged polycarbonate enclosure rated NEMA 4X / IP66, it is suitable for harsh industrial environments, including hazardous locations with FM, ATEX, and IECEx approvals. The ability to display multiple process variables and diagnostic data simultaneously makes it a highly efficient and user-friendly solution for continuous liquid analysis systems.
QTech Safety is a leading supplier of Rosemount 1066 Single Channel Transmitter in Ireland, offering competitive prices and fast worldwide shipping across United Kingdom (UK), Germany, France, Italy, Spain, United States USA, Canada, Mexico, and Western Australia (Perth). Buy Rosemount pH and ORP Meters from one of Ireland’s most trusted industrial safety equipment suppliers.
Features of Rosemount 1066 Single Channel Transmitter
- Single-channel input for liquid analytical measurement
- Measures pH, ORP, conductivity, oxygen, chlorine, ozone
- Loop-powered 2-wire (≥12.7 VDC) operation
- Large customizable LCD display with diagnostics
- Supports HART & FOUNDATION fieldbus communication
- Two 4–20 mA outputs for process signals
- Quick Start programming for fast setup
- Advanced SMART diagnostics & fault alerts
- Rugged NEMA 4X / IP66 enclosure
- Hazardous area approvals (FM, ATEX, IECEx)
Technical Specifications of Rosemount 1066
- Type: Single-input intelligent transmitter for liquid analysis
- Measurements: pH/ORP, Conductivity (contacting & toroidal), Dissolved Oxygen, Chlorine, Ozone
- Input: One sensor input
- Output: 4-20 mA with HART
- Power supply: 100–240 V AC or 24 V DC
- Display: Large backlit LCD with easy menus
- Enclosure: NEMA 4X / IP66, polycarbonate
- Ambient temperature: 0 to +50 °C (32 to 122 °F)
- Mounting: Wall, pipe, or panel mount
- Design: Four-wire, compact with advanced diagnostics
- Certifications: Hazardous area approvals available
pH Meters Part Number & Configuration Guide
Standard (Example) Part Number
1066-C-HT-60
This is a reference configuration for the Rosemount pH Meters. It represents one commonly supplied setup and helps customers understand how the part number is structured.
Configurable Part Number Format
1066-X-XX-XX
Each X / XX in the part number indicates a selectable option that can be customized based on your application requirements such as Measurement, Communication, Power & Agency Approval.
✅ Important: Final part number depends on the exact configuration needed for your machinery, environment, and monitoring system.
Applications
The Rosemount 1066 Single Channel Transmitter is commonly used in industrial calibration and testing applications, including:
- Water and wastewater treatment (pH, chlorine monitoring)
- Chemical processing and liquid analysis
- Power plant boiler water and condensate monitoring
- Food & beverage process quality control
- Pharmaceutical and industrial liquid analysis systems
