Rosemount 0304 Conventional Manifold
Rosemount 0304 Conventional Manifold is a robust instrument manifold designed for traditional remote mounting with pressure transmitters. It provides reliable isolation, equalization, and venting functions, ensuring accurate pressure measurement while reducing leak paths and improving system safety in industrial applications.
Looking for a Quote? Contact Us Now
Categories: Manifold
Description
The Rosemount 0304 Conventional Manifold is engineered for use with differential pressure transmitters where remote mounting is required. Unlike integral manifolds, it is installed separately using impulse lines, offering flexibility in system layout and maintenance. Available in 2-, 3-, and 5-valve configurations, it enables essential functions such as process isolation, equalization of pressure between ports, and venting or draining for safe calibration and servicing. Its conventional design is widely used in applications where space constraints, accessibility, or process conditions require separation between the transmitter and manifold. The manifold is factory tested to ensure leak-free performance and consistent operation.
In addition, the manifold is constructed from high-quality 316/316L stainless steel and optional alloy materials, providing excellent resistance to corrosion and harsh environments. It supports high-pressure and high-temperature operation, making it suitable for demanding industries such as oil & gas, chemical processing, and power generation. Standard 1/2–14 NPT connections allow easy integration with existing piping systems, while the durable valve design ensures long service life with minimal maintenance. With its flexibility, reliability, and proven performance, the 0304 Conventional Manifold remains a dependable solution for industrial pressure measurement systems.
QTech Safety is a leading supplier of Rosemount 0304 Conventional Manifold in Ireland, offering competitive prices and fast worldwide shipping across United Kingdom (UK), Germany, France, Italy, Spain, United States USA, Canada, Mexico, and Western Australia (Perth). Buy Rosemount Manifold from one of Ireland’s most trusted industrial safety equipment suppliers.
Features of Rosemount 0304 Conventional Manifold
- Conventional remote-mount manifold design
- Available in 2-, 3-, and 5-valve configurations
- Supports isolation, equalization, and venting functions
- Suitable for differential pressure transmitters
- Flexible installation with impulse line connections
- Factory tested for leak-free performance
- Rugged 316/316L stainless steel construction
- Designed for high-pressure and high-temperature applications
- Easy integration with standard piping systems
Technical Specifications of Rosemount 0304
- Type: Conventional (remote-mount) instrument manifold
- Valve configuration: 2-valve, 3-valve, or 5-valve
- Maximum operating pressure: Up to 6000 psi (413 bar)
- Maximum operating temperature: Up to 538°C (1000°F)
- Manifold material: 316/316L stainless steel, optional alloy materials
- Packing material: PTFE or graphite-based
- Process connection: 1/2–14 NPT female (standard)
- Mounting: Remote with impulse lines
- Design: Multi-valve body for isolation, equalization, and venting
- Assembly: Factory assembled and pressure tested
Manifold Part Number & Configuration Guide
Standard (Example) Part Number
0304RT25B11
This is a reference configuration for the Rosemount Manifold. It represents one commonly supplied setup and helps customers understand how the part number is structured.
Configurable Part Number Format
0304RXXXXXX
Each X / XX in the part number indicates a selectable option that can be customized based on your application requirements such as Manifold Style, Manifold Type, Design Class, Packing Material, Mounting Brackets, Bolts & Cleaning.
✅ Important: Final part number depends on the exact configuration needed for your machinery, environment, and monitoring system.
Applications
The Rosemount 0304 Conventional Manifold is commonly used in industrial calibration and testing applications, including:
- Differential pressure measurement systems
- Oil & gas process instrumentation
- Chemical and petrochemical plants
- Power generation pressure monitoring
- General industrial pressure control systems
