Rosemount 0306 Inline Manifold
Rosemount 0306 Inline Manifold is a compact, rugged instrument manifold designed for inline mounting with pressure transmitters and gauges. It simplifies installation, reduces leak paths, and provides reliable isolation and venting functions for accurate pressure measurement in industrial applications.
Looking for a Quote? Contact Us Now
Categories: Manifold
Description
The Rosemount 0306 Inline Manifold is engineered for direct inline installation between the process and pressure measurement device, making it ideal for gauge and absolute pressure transmitters. Its compact design minimizes space requirements while maintaining robust performance in demanding environments. The manifold is available in 2-valve and block-and-bleed configurations, allowing effective isolation and venting of process pressure for safe maintenance and accurate calibration. By reducing the number of fittings and connections, it lowers the risk of leakage and improves overall system reliability. The unit is factory assembled and pressure tested, ensuring dependable operation right from installation.
In addition, the manifold is constructed from high-quality 316/316L stainless steel and optional alloy materials, providing excellent resistance to corrosion and harsh process conditions. It supports flexible installation with standard 1/2–14 NPT connections and is suitable for both vertical and horizontal mounting orientations. The design includes durable valve stems with reliable sealing to withstand repeated operation in high-pressure environments. With its simple configuration, rugged build, and compatibility with a wide range of pressure instruments, the 0306 Inline Manifold offers a cost-effective and efficient solution for industrial pressure control systems.
QTech Safety is a leading supplier of Rosemount 0306 Inline Manifold in Ireland, offering competitive prices and fast worldwide shipping across United Kingdom (UK), Germany, France, Italy, Spain, United States USA, Canada, Mexico, and Western Australia (Perth). Buy Rosemount Manifold from one of Ireland’s most trusted industrial safety equipment suppliers.
Features of Rosemount 0306 Inline Manifold
- Inline mounting design for pressure transmitters and gauges
- Available in 2-valve and block-and-bleed configurations
- Reduces fittings and potential leak points
- Enables isolation and venting for maintenance and calibration
- Compact and space-saving construction
- Factory assembled and pressure tested
- Rugged 316/316L stainless steel construction
- Suitable for high-pressure industrial applications
- Flexible installation (horizontal or vertical mounting)
Technical Specifications of Rosemount 0306
- Type: Inline instrument manifold
- Valve configuration: 2-valve (block & bleed)
- Maximum operating pressure: Up to 6000 psi (413 bar)
- Maximum operating temperature: Up to 538°C (1000°F)
- Manifold material: 316/316L stainless steel, optional alloy materials
- Packing material: PTFE or graphite-based
- Process connection: 1/2–14 NPT female/male options
- Mounting: Inline with transmitter or pressure gauge
- Design: Compact body with reliable valve sealing
- Assembly: Factory assembled and leak-tested
Manifold Part Number & Configuration Guide
Standard (Example) Part Number
0306RT12AA11
This is a reference configuration for the Rosemount Manifold. It represents one commonly supplied setup and helps customers understand how the part number is structured.
Configurable Part Number Format
0306RTXXXXXX
Each X / XX in the part number indicates a selectable option that can be customized based on your application requirements such as Manifold Style, Manifold Type, Design Class, Packing Material, Mounting Brackets, Bolts & Cleaning.
✅ Important: Final part number depends on the exact configuration needed for your machinery, environment, and monitoring system.
Applications
The Rosemount 0306 Inline Manifold is commonly used in industrial calibration and testing applications, including:
- Differential pressure measurement systems
- Oil & gas process instrumentation
- Chemical and petrochemical plants
- Power generation pressure monitoring
- General industrial pressure control systems
