Dwyer EDA Electronic Pressure Controller
Dwyer EDA Electronic Pressure Controller is a multifunctional pressure control device that combines a digital pressure gauge, dual pressure switches, and transmitter output in one compact unit. It delivers accurate pressure monitoring, programmable control, and reliable performance for HVAC, industrial automation, and process control applications.
Looking for a Quote? Contact Us Now
Categories: Pressure Controllers
Description
The Dwyer EDA Electronic Pressure Controller is engineered to replace multiple individual instruments with a single integrated solution, reducing installation cost, wiring complexity, and panel space requirements. It incorporates a high-accuracy solid-state pressure sensor with up to ±1% full-scale accuracy, providing precise and repeatable pressure measurement for both liquids and gases. The controller features two fully programmable SPDT relays with adjustable on/off setpoints for alarm or control functions, allowing independent operation for pumps, compressors, filters, and HVAC systems. A large backlit LCD display provides real-time process values and selectable engineering units such as psi, bar, kPa, inHg, and more. LED indicators on the front panel clearly display relay status for quick diagnostics and monitoring.
In addition, the EDA controller includes advanced programmable features such as adjustable damping, fail-safe operation, peak and valley indication, scalable transmitter output, and adjustable time delay. The rugged NEMA 4X/IP66 weatherproof enclosure allows reliable operation in harsh industrial environments and supports panel, flush, or pipe mounting. Models are available with optional analog outputs including 4–20 mA and multiple voltage signals for seamless integration with PLCs, SCADA systems, and building automation systems (BMS). With support for pressure ranges up to 3000 psi and durable 316 stainless steel wetted parts, the EDA Series provides a highly versatile and dependable pressure monitoring and control solution for demanding industrial applications.
QTech Safety is a leading supplier of Dwyer EDA Electronic Pressure Controller in Ireland, offering competitive prices and fast worldwide shipping across United Kingdom (UK), Germany, France, Italy, Spain, United States USA, Canada, Mexico, and Western Australia (Perth). Buy Dwyer Instruments Pressure Controllers from one of Ireland’s most trusted industrial safety equipment suppliers.
Features of Dwyer EDA Electronic Pressure Controller
- Combines pressure gauge, dual switch, and transmitter in one unit
- Two programmable SPDT relays for control and alarms
- High accuracy up to ±1% full scale
- Large backlit LCD display with selectable engineering units
- LED relay status indicators on front panel
- Supports 4–20 mA and voltage outputs
- Advanced features: peak/valley, damping, fail-safe, time delay
- Rugged NEMA 4X / IP66 weatherproof enclosure
- Compatible with PLC, SCADA, and BMS systems
- Flexible mounting: panel, flush, or pipe mount
Technical Specifications of Dwyer EDA Series
- Type: Electronic pressure controller / digital pressure switch
- Measurement range: 0–20 psi up to 0–3000 psi (model dependent)
- Accuracy: ±1% of full scale including linearity, hysteresis, and repeatability
- Display: 4-digit backlit LCD display
- Output signal: 4–20 mA, 1–5 VDC, 0–5 VDC, 1–6 VDC, or 0–10 VDC (model dependent)
- Switch type: (2) SPDT relays
- Switch rating: 5 A @ 120/240 VAC, 1 A @ 30 VDC
- Power supply: 12–30 VDC/AC or 120/240 VAC (model dependent)
- Operating temperature: 20 to 140 °F (-6.6 to 60 °C)
- Process temperature: 0 to 176 °F (-18 to 80 °C)
- Enclosure rating: NEMA 4X / IP66
- Wetted materials: 316 stainless steel
- Housing material: Polycarbonate / glass-filled plastic
- Process connection: 1/4″ NPT male
- Warm-up time: <10 seconds
- Mounting: Panel, flush, or pipe mount
- Weight: Approximately 1.18 lb (535 g)
Pressure Controllers Part Number & Configuration Guide
Standard (Example) Part Number
EDAW-N1E1-02T0
This is a reference configuration for the Dwyer Instruments Pressure Controllers. It represents one commonly supplied setup and helps customers understand how the part number is structured.
Configurable Part Number Format
EDAW-N1E1-0XXX
Each X / XX in the part number indicates a selectable option that can be customized based on your application requirements such as Aluminum Adhesive Tag, NIST Certificate, Pressure Range, 1/2 NPSM Conduit Plug & Output.
✅ Important: Final part number depends on the exact configuration needed for your machinery, environment, and monitoring system.
Applications
The Dwyer EDA Electronic Pressure Controller is commonly used in industrial calibration and testing applications, including:
- HVAC pressure monitoring and control
- Compressor and pump automation systems
- Industrial process pressure control
- Filter status and differential pressure monitoring
- SCADA and building automation systems
