Dwyer A3000 Photohelic Pressure Switch
Dwyer A3000 Photohelic Pressure Switch is a combination differential pressure gauge and pressure switch designed for accurate monitoring and control of air and compatible gases. It provides both local visual indication and automatic control output, making it ideal for HVAC systems, cleanrooms, and industrial air handling applications.
Looking for a Quote? Contact Us Now
Categories: Pressure Gauges
Description
The Dwyer A3000 Photohelic Pressure Switch integrates a Magnehelic-type mechanical pressure gauge with dual high and low setpoint switches in a single unit. It measures low differential pressure using a diaphragm-based system and displays the value on a clear analog dial while simultaneously providing switch outputs for control functions. The setpoints are fully adjustable and allow users to trigger alarms or control equipment such as fans, dampers, or filters when pressure exceeds or drops below defined limits. This dual-function design eliminates the need for separate gauge and switch installations, reducing system complexity and cost.
In addition, the device features a rugged die-cast aluminum housing with a clear acrylic lens for durability and visibility in industrial environments. It offers reliable snap-action switching for consistent performance and long service life with minimal maintenance. The A3000 is suitable for panel mounting and supports a wide range of low-pressure scales, making it highly versatile for HVAC and process air monitoring applications. Its combination of indication and control in one compact instrument makes it a widely used solution in air management systems.
QTech Safety is a leading supplier of Dwyer A3000 Photohelic Pressure Switch in Ireland, offering competitive prices and fast worldwide shipping across United Kingdom (UK), Germany, France, Italy, Spain, United States USA, Canada, Mexico, and Western Australia (Perth). Buy Dwyer Instruments Pressure Gauge from one of Ireland’s most trusted industrial safety equipment suppliers.
Features of Dwyer A3000 Photohelic Pressure Switch
- 3-in-1 Indicating Gauge, Lo-Limit and Hi-Limit Control
- For use with air and non-combustible gases
- Ranges: to 150 inH2O, 30 psi, 8 kPa, 80 mmH2O, or 80 cmH2O. Some bidirectional ranges available
- Accuracy: up to ±2% of FS at 70°F
- 1/8″ female NPT process connection
- Zero adjustment screw
- 4″ dial face
- Pressure Switches: 2 Form C relays (DPDT) for each setpoint
- Set Point Adjustment: Adjustable knobs on face
- Repeatability: ±1% of FS
- CE, CSA, UL approved. Optional-EXPL explosion-proof enclosure does not possess any agency approvals
Technical Specifications of Dwyer A3000
- Type: Differential pressure gauge with dual pressure switch
- Measurement range: Low differential pressure ranges (e.g., 0–0.25 to 0–100 in. w.c.)
- Switch type: SPDT snap-action switches (high and low setpoints)
- Accuracy: ±2% full scale (gauge)
- Operating temperature: -6.7 to 60 °C (20 to 140 °F)
- Media compatibility: Air and non-combustible, compatible gases
- Maximum pressure: 15 psig (1.03 bar)
- Electrical rating: Typically up to 15 A @ 120–240 VAC (switch dependent)
- Process connection: 1/8″ NPT female (dual ports)
- Case material: Die-cast aluminum
- Lens material: Clear acrylic
- Mounting: Panel mount
- Adjustment: External adjustable high and low setpoints + zero adjustment
Pressure Gauges Part Number & Configuration Guide
Standard (Example) Part Number
A3201
This is a reference configuration for the Dwyer Instruments Pressure Gauges. It represents one commonly supplied setup and helps customers understand how the part number is structured.
Configurable Part Number Format
A3XXX - XXX
Each X / XX in the part number indicates a selectable option that can be customized based on your application requirements such as Pressure Type, Connection Type, Pressure Range & Transmitter Output.
✅ Important: Final part number depends on the exact configuration needed for your machinery, environment, and monitoring system.
Applications
The Dwyer A3000 Photohelic Pressure Switch is commonly used in industrial calibration and testing applications, including:
- HVAC duct and airflow monitoring
- Air filter condition indication
- Cleanroom pressure monitoring
- Fan and blower pressure measurement
- Industrial ventilation systems
