Bently Nevada 3500/22M Data Interface Module
The Bently Nevada 3500/22M Data Interface Module (TDI) links the 3500 monitoring system to software like System 1 and 3500 System Configuration, combining RIM and communication processor functions. Installed next to the rack power supplies, it continuously collects steady-state and transient data from M-series monitors and sends it via Ethernet. The TDI supports static data capture by default and, with an optional Channel Enabling Disk, can record high-resolution dynamic data, all without affecting the rack’s critical monitoring path.
Looking for a Quote? Contact Us Now
Categories: Vibration Monitor
Description
The Bently Nevada 3500/22M Data Interface Module (TDI) serves as the link between the 3500 monitoring system and compatible software, including System 1 Condition Monitoring and 3500 System Configuration. It combines the functions of a 3500/20 Rack Interface Module (RIM) with the data collection capabilities of a communication processor, allowing continuous capture of steady-state and transient waveform data from M-series monitors (3500/40M, 3500/42M, etc.) and forwarding it via Ethernet to host software.
The TDI fits in the slot next to the 3500 rack power supplies and supports static data capture by default. With an optional Channel Enabling Disk, it can also record dynamic and high-resolution transient data. While the TDI handles data collection and communication, it does not interfere with the rack’s critical monitoring path or the normal operation of machinery protection. Every 3500 rack requires one TDI or RIM, always installed in Slot 1.
QTech Safety is a leading supplier of Bently Nevada 3500/22M Data Interface Module in Ireland, offering competitive prices and fast worldwide shipping across United Kingdom (UK), Germany, France, Italy, Spain, United States USA, Canada, Mexico, and Western Australia (Perth). Buy Bently Nevada Vibration Monitor from one of Ireland’s most trusted industrial safety equipment suppliers.
Features of Bently Nevada 3500/22M Data Interface Module
- 10.5 Watts power consumption
- USB-B front panel
- 10Base-T or 100Base-TX Ethernet, autosensing
- 100Base-FX Fiber-Optic Ethernet
- Rack reset button
- Pre and post-alarm data
- LED indicator
- I/O module relay
Technical Specifications of Bently Nevada 3500/22M Data Interface Module
Purpose: Connects 3500 Rack to external systems (DCS/PLC/SCADA)
Protocols: Modbus® RTU/TCP
Data: Process values, alarms, health, vibration/position measurements
Ports: Ethernet 10/100 Base‑T, RS‑232/RS‑485
Isolation: Galvanic for noise immunity
Indicators: LEDs for network, TX/RX, module status
Configuration: 3500 Rack Configuration Software
Mounting: 3500 series rack
Power: <10 W
Operating temp: –30 °C to +65 °C
Storage temp: –40 °C to +85 °C
Humidity: Up to 95 % non‑condensing
Compatibility: All 3500 series modules
Vibration Monitor Part Number & Configuration Guide
Standard (Example) Part Number
3500/22-01-01-00
This is a reference configuration for the Bently Nevada 3500/22M Data Interface Module. It represents one commonly supplied setup and helps customers understand how the part number is structured.
Configurable Part Number Format
3500/22-01-XX-XX
Each X / XX in the part number indicates a selectable option that can be customized based on your application requirements such as I/O Module Type & Approvals.
✅ Important: Final part number depends on the exact configuration needed for your machinery, environment, and monitoring system.
Applications
The Bently Nevada 3500/22M Data Interface Module is commonly used in monitoring and managing rotating machinery, including:
Connecting 3500 racks to System 1 or 3500 Configuration software
Collecting steady-state and transient vibration data
Recording dynamic/high-resolution data with an optional disk
Sending data via Ethernet to host systems
Non-intrusive capture without affecting machine protection
