Siemens 6ES7214-1BG40-0XB0 SIMATIC S7-1200 CPU 1214C
The Siemens 6ES7214-1BG40-0XB0 is a SIMATIC S7-1200 CPU 1214C with a DC/DC/Relay configuration, combining the higher I/O count of the 1214C with relay-based digital outputs. It comes with a built-in power supply, onboard digital and analog I/O, and a PROFINET port, so it runs as a standalone controller without needing extra modules. The relay outputs make it well-suited for driving contactors, solenoids, and motor starters directly, without adding external interposing relays.
Looking for a Quote? Contact Us Now
Categories: Programmable Logic Controller (PLC)
Tags: SIMATIC S7-1200 CPUs
Description
The Siemens SIMATIC S7-1200 CPU 1214C DC/DC/Relay runs on a 24V DC power supply for the CPU itself, but uses relay outputs instead of transistor outputs, giving it the flexibility to switch both AC and DC loads directly. It comes with 14 digital inputs, 10 relay outputs, and 2 analog inputs built directly into the unit, so larger machines can be wired and running without needing separate I/O modules. This CPU is programmed using TIA Portal (STEP 7 V13 SP1 or higher) and supports LAD, FBD, and SCL programming languages.
The CPU 1214C DC/DC/Relay includes a PROFINET port for network communication, supports open Ethernet protocols such as TCP/IP and Modbus, and has a built-in web server for remote diagnostics. It also comes with useful onboard functions such as high-speed counting, frequency measurement, and a PID controller for closed-loop process control. It can be expanded with 1 signal board, 8 signal modules, and up to 3 communication modules, giving plenty of room to grow the system later.
QTech Safety is a leading supplier of Siemens 6ES7214-1BG40-0XB0 SIMATIC S7-1200 CPU 1214C in Ireland, offering competitive prices and fast worldwide shipping across United Kingdom (UK), Germany, France, Italy, Spain, United States USA, Canada, Mexico, and Western Australia (Perth). Buy Siemens PLC Modules from one of Ireland’s most trusted industrial safety equipment suppliers.
Features of Siemens 6ES7214-1BG40-0XB0 SIMATIC S7-1200 CPU 1214C
- Compact all-in-one design with built-in power supply, inputs, and outputs
- Relay outputs rated for both AC and DC loads, ideal for switching contactors and solenoids
- 14 built-in digital inputs and 10 built-in relay outputs
- 2 built-in analog inputs (0 to 10V)
- Onboard PROFINET port for easy network connection
- Built-in web server for remote diagnostics and monitoring
- High-speed counting up to 100 kHz on multiple channels
- Built-in PID controller for process control loops
- Frequency measurement function built in
- Expandable with 1 signal board, 8 signal modules, and up to 3 communication modules
- Real-time clock with battery-free backup for up to 480 hours
- Programmable using LAD, FBD, and SCL in TIA Portal
Technical Specifications of Siemens 6ES7214-1BG40-0XB0
- Product type: CPU 1214C DC/DC/Relay
- Programming software: STEP 7 V13 SP1 or higher (TIA Portal)
- Rated voltage: 24V DC
- Voltage range: 20.4V to 28.8V DC
- Reverse polarity protection: Yes
- Current consumption: 500 mA (CPU only), up to 1,500 mA with all expansion modules
- Inrush current: Up to 12 A at 28.8V DC
- Power loss: 12 W typical
- Program/data memory: 150 KB
- Load memory: 4 MB integrated, expandable with SIMATIC Memory Card
- Retentive memory: Up to 10 KB
- Backup: Maintenance-free, battery-free
- Bit operations: 0.085 µs per instruction
- Word operations: 1.7 µs per instruction
- Floating point arithmetic: 2.5 µs per instruction
- Digital inputs: 14, integrated
- Usable for high-speed counting: 6 channels
- Rated input voltage: 24V DC
- Max cable length: 500 m shielded / 300 m unshielded
- Digital outputs: 10, relay type
- Switching capacity: 2 A resistive load per output
- Lamp load rating: 30 W (DC) / 200 W (AC)
- Relay mechanical life: 10 million operations
- Relay life at rated load: 100,000 operations
- Max cable length: 500 m shielded / 150 m unshielded
- Analog inputs: 2
- Input range: 0 to 10V DC
- Resolution: 10-bit
- Analog outputs: 0 (none built in on this model)
- Interface type: PROFINET (Ethernet)
- Number of ports: 1
- PROFINET IO Controller: Yes
- PROFINET IO Device: Yes
- Max transmission rate: 100 Mbit/s
- Protocols supported: TCP/IP, ISO-on-TCP, UDP, Modbus, S7 communication
- Max connectable IO devices: 16
- Web server: Yes, with user-defined web pages
- Counters: 6, up to 100 kHz
- Frequency measurement: Yes
- Positioning control: Yes
- PID controller: Yes
- Alarm inputs: 4
- Hardware clock: Yes
- Backup time: 480 hours typical
- Accuracy: ±60 seconds/month at 25°C
- Digital input isolation: 500V AC for 1 minute
- Digital output isolation: Relay-based, in groups of 2
- Permissible potential difference: 500V DC between 24V DC and 5V DC circuits
- Degree of protection: IP20
- Approvals: CE, UL, cULus, FM, RCM, Marine approval
- Operating temperature: -20°C to 60°C (horizontal), -20°C to 50°C (vertical)
- Storage temperature: -40°C to 70°C
- Humidity: Up to 95%, non-condensing
- Dimensions (W x H x D): 110 x 100 x 75 mm
- Weight: 455 g approx.
Applications
The Siemens 6ES7214-1BG40-0XB0 SIMATIC S7-1200 CPU 1214C is commonly used in:
- Mid-size machine control requiring relay-driven output switching
- Direct control of contactors, solenoids, and motor starters
- Mixed AC/DC load switching applications
- Packaging, material handling, and conveyor systems
- Retrofit projects replacing relay-logic control systems
- HVAC and building automation with relay-based actuators
- Systems needing more onboard I/O with relay switching flexibility
