Rosemount 214C Thermocouple
Rosemount 214C Thermocouple is an industrial temperature sensor designed for accurate and reliable measurement in harsh process environments. It uses thermocouple technology (Types J, K, and T) and provides a wide operating range from very low cryogenic temperatures up to high-temperature industrial processes, making it suitable for demanding applications.
Looking for a Quote? Contact Us Now
Categories: Thermocouple, Thermocouple Temperature Sensors
Description
The Rosemount 214C Thermocouple Temperature Sensor is built to deliver flexible and durable temperature measurement across a broad range of industrial conditions. It supports Type J, Type K, and Type T thermocouples, covering temperatures from approximately -321°F to 2192°F (-196°C to 1200°C), depending on the selected type. The sensor is designed with robust construction for high-vibration environments and offers both grounded and ungrounded junction options, allowing users to balance response time and noise immunity based on process needs. It is available in single or dual element configurations and can be customized with different insertion lengths, typically up to 78.5 inches, making it adaptable to various thermowell and installation requirements.
In addition, the sensor is engineered for high reliability with insulation resistance up to 1000 MΩ at 500 VDC, ensuring strong electrical isolation in industrial conditions. It also features fast response times (around 2.2 seconds for grounded junctions and slightly higher for ungrounded versions), enabling quick temperature tracking in dynamic processes. The 214C is designed to integrate easily with Rosemount temperature transmitters and thermowells, forming a complete temperature measurement system for oil & gas, chemical processing, power generation, and general industrial applications.
QTech Safety is a leading supplier of Rosemount 214C Thermocouple in Ireland, offering competitive prices and fast worldwide shipping across United Kingdom (UK), Germany, France, Italy, Spain, United States USA, Canada, Mexico, and Western Australia (Perth). Buy Rosemount Thermocouple Temperature Sensor from one of Ireland’s most trusted industrial safety equipment suppliers.
Features of Rosemount 214C Thermocouple Sensor
- Thermocouple types: J, K, T
- Temperature range: -196°C to 1200°C (-321°F to 2192°F)
- Fast response time: ~2.2 sec (grounded junction)
- High insulation resistance: 1000 MΩ @ 500 VDC
- Single or dual element construction
- Grounded or ungrounded junction options
- Wide range of insertion lengths (up to ~2000 mm / 78.5 in)
- Rugged design for high vibration environments
- Compatible with thermowells and transmitters
Technical Specifications of Rosemount 214C Thermocouple
- Type: Industrial Thermocouple sensor
- Sensor types: Type J, K, T, E, N, R, S
- Temperature range: -196 to +1200 °C (-321 to +2192 °F) depending on type
- Accuracy: Standard or Special Limits of Error per ASTM E230
- Sheath material: 316L Stainless Steel (standard)
- Sheath diameters: 3 mm, 4.5 mm, 6 mm, or ¼ in.
- Lead wire types: PTFE, fiberglass, or mineral insulated cable
- Junction types: Grounded, Ungrounded, Exposed
- Mounting styles: Threaded, flanged, spring-loaded
- Response time: Fast (typically 1–5 seconds)
- Certifications: Hazardous area approvals available
Thermocouple Sensor Part Number & Configuration Guide
Standard (Example) Part Number
214CTJSSSTSGE0020SO
This is a reference configuration for the Rosemount Thermocouple Temperature Sensor. It represents one commonly supplied setup and helps customers understand how the part number is structured.
Configurable Part Number Format
214CTXXXXXXXXXXXXXX
Each X / XX in the part number indicates a selectable option that can be customized based on your application requirements such as Certifications, Software Configuration, Sensor Type, Sensor Sheath Material, Sensor Accuracy, Dimension Units, Sensor Mounting Style & Warranty.
✅ Important: Final part number depends on the exact configuration needed for your machinery, environment, and monitoring system.
Applications
The Rosemount 214C Thermocouple Sensor is commonly used in industrial calibration and testing applications, including:
- Oil & gas process temperature measurement
- Power plant boilers and turbines
- Chemical and petrochemical processing
- Food & beverage temperature monitoring
- General industrial temperature sensing
