Druck DPI610E Pressure Calibrator
Druck DPI610E Pressure Calibrator is a portable pressure calibrator with integrated pressure generation and measurement capabilities. It provides accurate calibration of pressure instruments, supports electrical measurements, and is ideal for field and laboratory use in industrial process control and instrumentation applications.
Looking for a Quote? Contact Us Now
Categories: Pressure Calibrator
Description
The Druck DPI610E is a portable pressure calibrator designed for accurate measurement and generation of pressure signals in industrial environments. It features an integrated pressure pump, allowing users to generate and control pressure without external equipment. The device supports a wide range of pressure ranges and provides high-accuracy readings, making it ideal for calibrating pressure transmitters, gauges, and switches.
In addition to pressure calibration, the DPI610E offers electrical measurement capabilities, including current and voltage, enabling complete loop testing and instrument verification. Its rugged, handheld design makes it suitable for field use, while its user-friendly interface ensures efficient operation. Widely used in industries such as oil & gas, power, and manufacturing, it helps improve maintenance accuracy and system reliability.
QTech Safety is a leading supplier of Druck DPI610E Pressure Calibrator in Ireland, offering competitive prices and fast worldwide shipping across United Kingdom (UK), Germany, France, Italy, Spain, United States USA, Canada, Mexico, and Western Australia (Perth). Buy Druck Pressure Calibrator from one of Ireland’s most trusted industrial safety equipment suppliers.
Features of Druck DPI610E Pressure Calibrator
- 100,000 point data logging memory
- HART communication as standard on all versions
- Integral calibration record with calibration due countdown
- Hazardous area (Intrinsically safe) versions available
- Built-in barometer (pneumatic pressure version)
- 4.4in backlit high-contrast display
- IP54 protection rated
- CE marked, UKCA marked
- Hazardous Area version: ATEX, IECex, UKEX to EN60079-11:2012 Ex ia IIC T4 Ga (-10 to 50°C)
Technical Specifications of Druck DPI610E
- Type: Handheld portable pressure calibrator with built-in manual pump
- Power supply: Rechargeable Li-ion battery
- Battery life: Over 24 hours continuous use (up to 60+ hours in low power mode)
- Display: 112 mm (4.4 inch) backlit touchscreen LCD
- Pressure generation: Integrated hand pump with fine volume adjuster
- Pressure range (pneumatic): 95% vacuum to 35 bar (500 psi)
- Pressure range (hydraulic): Up to 1000 bar (15,000 psi)
- Accuracy: 0.025% FS (1-year total uncertainty, -10°C to +50°C)
- Internal barometer: Yes, for pseudo-absolute pressure
- Electrical: Measures/sources mA and voltage, 24V loop power
- Communication: HART as standard
- Data logging: 100,000 points with documenting capability
- Connectivity: USB port
- Operating temperature: -10°C to +50°C
- Protection: IP54
- Weight (approx.): Pneumatic 3.6 kg, Hydraulic 4.4 kg
- Options: Intrinsically safe (IS) versions available
Pressure Calibrator Part Number & Configuration Guide
Standard (Example) Part Number
DPI610E-PC-03G-U0-B0
This is a reference configuration for the Druck Pressure Calibrator. It represents one commonly supplied setup and helps customers understand how the part number is structured.
Configurable Part Number Format
DPI610E-XX-XXX-XX-XX-X
Each X / XX in the part number indicates a selectable option that can be customized based on your application requirements such as Calibrator, Bluetooth Connectivity, Pressure Base Station & Pressure Modules.
✅ Important: Final part number depends on the exact configuration needed for your machinery, environment, and monitoring system.
Applications
The Druck DPI610E Pressure Calibrator is commonly used in industrial calibration and testing applications, including:
- Calibration of pressure transmitters and gauges
- Testing pressure switches and sensors
- Performing loop checks (4–20 mA systems)
- Used in oil & gas and chemical industries
- Maintenance of process instrumentation systems
- Field calibration in power plants and factories
- Troubleshooting industrial pressure systems
