Bently Nevada 3500/64M Dynamic Monitor
The Bently Nevada 3500/64M Dynamic Monitor is a single-slot, four-channel module that accepts inputs from high-temperature pressure transducers and measures band-pass dynamic pressure. It continuously compares signals with user-configured alarm setpoints to provide machinery protection, supports configurable filters through the 3500 Rack Configuration Software, and offers a recorder output for control system integration and operational monitoring.
Looking for a Quote? Contact Us Now
Categories: Vibration Monitor
Description
The Bently Nevada 3500/64M Dynamic Monitor is a single-slot, four-channel module that accepts inputs from high-temperature pressure transducers. It measures band-pass dynamic pressure on each channel and continuously compares the signals with configured alarm setpoints to provide reliable machinery protection and alarm activation.
The Bently Nevada 3500/64M Dynamic Monitor uses the 3500 Rack Configuration Software to set band-pass corner frequencies and apply an additional notch filter for precise signal processing. It also provides a recorder output for control system integration, delivering essential machine data to operations and maintenance personnel while ensuring continuous protection.
QTech Safety is a leading supplier of Bently Nevada 3500/64M Dynamic Monitor in Ireland, offering competitive prices and fast worldwide shipping across United Kingdom (UK), Germany, France, Italy, Spain, United States USA, Canada, Mexico, and Western Australia (Perth). Buy Bently Nevada Vibration Monitor from one of Ireland’s most trusted industrial safety equipment suppliers.
Features of Bently Nevada 3500/64M Dynamic Monitor
Accepts 1 to 4 pressure transducer inputs
Input impedance: 10 kΩ (3-wire), 1.5–3.5 MΩ typical (2-wire)
Dynamic pressure sensitivity: 100 mV/psi (1.45 mV/mbar)
Front panel LEDs: OK, TX/RX, Bypass
High and low operating modes available
Programmable alarm time delays
Technical Specifications of Bently Nevada 3500/64M Dynamic Monitor
Channels: 1 to 4 pressure transducer inputs
Input types: High-temperature pressure transducers
Input impedance: 10 kΩ (3-wire); 1.5–3.5 MΩ typical (2-wire)
Dynamic pressure sensitivity: 100 mV/psi (1.45 mV/mbar)
Measurement function: Band-pass dynamic pressure
Alarm capability: User-programmable alarm time delays
Modes: High and low operating modes available
Configuration: 3500 Rack Configuration Software (band-pass and notch filters)
Outputs: Recorder output for control systems
Front panel indicators: LEDs for OK, TX/RX, Bypass
Mounting: Fits in 3500 series rack
Power consumption: ~7–9 W (typical)
Operating temperature: –30 °C to +65 °C (–22 °F to +149 °F)
Storage temperature: –40 °C to +85 °C (–40 °F to +185 °F)
Humidity tolerance: Up to 95 % non-condensing
System integration: Compatible with Bently Nevada 3500 series
Vibration Monitor Part Number & Configuration Guide
Standard (Example) Part Number
3500/64-01-00
This is a reference configuration for the Bently Nevada 3500/64M Dynamic Monitor. It represents one commonly supplied setup and helps customers understand how the part number is structured.
Configurable Part Number Format
3500/64-XX-XX
Each X / XX in the part number indicates a selectable option that can be customized based on your application requirements such as Number of Channels, I/O Module Type & Approvals.
✅ Important: Final part number depends on the exact configuration needed for your machinery, environment, and monitoring system.
Applications
The Bently Nevada 3500/64M Dynamic Monitor is commonly used in industrial machinery protection and dynamic pressure monitoring, including:
Monitoring combustion dynamic pressure in gas turbines
Detecting pressure pulsations and instabilities
Protecting turbines and compressors from combustion-related damage
Providing dynamic pressure alarm and trip inputs
Supplying recorder output to control and monitoring systems
Integrating with 3500 series machinery protection systems
